Solar Cables

Atula Cable Industries Solar cables are designed for connecting photovoltaic power supply systems.They are dedicated to the photovoltaic system direct current (D.C.) side with a nominal D.C. voltage of a 1.5kV. These cables can be used indoor & outdoor for flexible and fixed installations with high mechanical strength in extreme weather conditions. cables are designed to withstand the demanding environmental conditions that arise in any fixed, mobile, roof or architecturally integrated photovoltaic installation.

Wires and cables used in the renewable energy industry are crucial to the infrastructure, ensuring efficient transmission and distribution of energy from sources such as solar, wind, hydro, and geothermal power. These cables must meet stringent industry requirements, including UV resistance, heat resistance, and longevity. Specific cables, such as solar DC cables and wires, must accommodate the unique conditions and demands of renewable energy systems. These cables need to withstand harsh environmental conditions, resist chemicals like oils, and conduct high electrical performance efficiently. Additionally, renewable energy cables should be low-smoke, zero-halogen (LSZH) to emit low levels of smoke and be free from halogens, minimising health and environmental hazards.

Colors:
Nominal Cross Section Area (Sq. mm) Insulation Thickness (mm) Outer Sheath Thickness (mm) Approx. Cable Diameter (mm) Current Capacity - Free in Air (A) Current Capacity - On Surface (A) Current Capacity - Two Cables Touching (A) Max. Conductor Resistance at 20°C (Ω/km)
1.5 0.70 0.80 4.66 30 29 24 13.7
2.5 0.70 0.80 5.09 41 39 33 8.21
4 0.70 0.80 5.59 55 52 44 5.09
6 0.70 0.80 6.13 70 67 57 3.39
10 0.70 0.80 7.07 98 93 79 1.95
16 0.70 0.90 8.32 132 125 107 1.24
25 0.90 1.00 10.14 176 167 142 0.795
35 0.90 1.10 11.49 218 207 176 0.565
50 1.00 1.20 13.33 276 262 221 0.393
70 1.10 1.20 15.19 347 330 278 0.277
95 1.10 1.30 16.94 416 395 333 0.210
120 1.20 1.30 18.71 488 464 390 0.164
  • RoHS compliant
  • Temp. at Conductor: 150°C (20,000 h)
  • Better ageing resistance
  • Short Circuit Temp: 250°C
  • Electron Beam Cross-Linked
  • Flexibility & strip ability for fast and easy installation
  • Improved oil & chemical resistance & improved crack resistance
  • Improved electrical, mechanical, thermal & weather properties in elevated temperature conditions
  • Halogen Free, Flame Retardant, Fire Retardant, Low Smoke Emission
  • Test Voltage: 6500V AC for 5 minutes max.
  • Better UV & ozone resistance and improved weather resistance in adverse conditions
