CCTV Camera Cable

Atula Cable Industries CCTV Cables deliver clear, stable, and reliable connections for surveillance systems. They use high-grade copper conductors and a coaxial core, so they transmit video smoothly with minimal distortion or signal loss. Moreover, these cables come in 3 + 1 and 4 + 1 variants and are available in both special parallel and round designs, making them suitable for homes, offices, shops, and industrial setups.

In addition, durable insulation protects the cables from interference and ensures uninterrupted monitoring. At the same time, their flexible construction allows quick and hassle-free installation. As a result, CCTV cables create a strong and dependable foundation for your security system and help you keep every corner under constant watch.

High-performance cables engineered for carrying crystal-clear video signals (75 Ohms Coaxial) alongside integrated audio and 12V power distribution. Designed to reduce noise to the minimum while ensuring zero-lag transmission for modern security networks.

Colors:

Verified parameters according to Indian Standard protocols (IEC 61196-1)

Type Coaxial (RG-6, RG-11)
Signal Type Video Signal
Impedance 75 Ohms
Frequency Range 50–2000 MHz
Power / Audio Cores 14/0.2 mm Stranded Copper
Shielding TC / BC / Al Alloy
Video Quality 4K Ready, Zero-lag
Noise Reduction Advanced filtering
Core Insulation PE / Virgin PVC
Available Sizes 3+1, 4+1
Packing 180 Meter Coil
DC Resistance (Inner Conductor) Max. 62.0 Ω/Km at 20°C
Braid Resistance Max. 75.0 Ω/Km at 20°C
Loop Resistance Max. 138.0 Ω/Km at 20°C
Capacitance Between Inner & Outer Conductor ≤ 158.00 pF/meter
Flexible Power Cores Resistance Maximum 155.0 Ω/Km @ 20°C
  • 75 Ohms Signal Quality
  • 24 AWG Solid Copper Conductor
  • Virgin Flexible PVC Outer Sheath
  • H.D.P.E / L.D.P.E Insulation
  • Noise Reduction Technology
  • Twisted Core Symmetry
