CAT 5E UTP DOUBLE JACKET OUTDOOR Cable

Atula Cables Industries As a trusted Ethernet LAN cable manufacturer,offer enhanced headroom beyond TIA-568-C.2 and ISO/IEC 11801 Category 5e standards, ensuring reliable transmission with reduced crosstalk and consistent performance. Available in UTP variants, each built with solid bare copper conductors (24 AWG), quality insulation and selectable PVC, LSZH, or PE sheathing.

CAT 5 (Category 5) and CAT 5e (Enhanced) are twisted-pair copper cables essential for Ethernet networking, supporting data transmission in LANs. While original CAT 5 is limited to 100 Mbps, CAT 5e supports higher speeds up to 1 Gbps (1000 Mbps) and reduces interference, making it the preferred standard for modern home/office connections.

As a leading Cat 5e cable manufacturer, LAN cable manufacturer and networking cables manufacturer, Atula Cables Industrys delivers durable, high-integrity cabling solutions tailored for offices, commercial sites and data centers.

Conductor	24 AWG Solid Bare Copper
Insulation	High Density Polyethylene
Solid Pairs	4 Pairs Twisted together
Cable Diameter	6.0 ± 0.5 mm
Rip Cord	Nylon Rip cord
Inner Jacket	FR-PVC sheath (LSZH on request)
Outer Jacket	PVC/PE sheath (LSZH on request)
Jacket Colour	Black (Customised colours)
Bending Radius	4 X OD at 20°C
Pulling Force	25 lbs
Operating Temperature	(-20°C to +60°C)
Installation Temperature	(0°C to +50°C)

Conductor Resistance	9.2 Ω/100 Mtr max
Mutual Capacitance	5.6 nF for 100 Mtr
Resistance Unbalance (%)	max 5
Capacitance Unbalance	330 pF for 100 Mtr
Delay Skew	48 ns/100 Mtr
Propagation Delay	< 536 ns/100 Mtr
NVP	69%
Current Rating	max 1.5 A
Operating Voltage	72 V
Dielectric Strength	1000 V RMS

For Data Center Applications
High bandwidth @ 1000 MHz
4 Pair 24 AWG
Inner FR-PVC jacket
Outer PVC/PE jacket
High speed transmission of Voice, Video and Data on LAN
Complies to ANSI/TIA-568-C.2, ISO/IEC 11801

Pair Number	Colour
1 – 2	White-Orange Stripe and Orange
3 – 6	White-Green Stripe and Green
4 – 5	White-Blue Stripe and Blue
7 – 8	White-Brown Stripe and Brown

Frequency (MHz)	ATT (dB @ 100m) max	NEXT (dB) min	PS NEXT (dB) min	ACRF (dB @ 100m) min	PS ACRF (dB @ 100m) min	Return Loss (dB @ 100m) min
1	2.2	60	57.0	57.4	54.4	17.0
4	4.5	53.5	50.5	45.4	42.5	17.0
8	6.3	48.6	45.6	39.3	36.3	17.0
10	7.1	47.0	44.0	37.4	34.4	17.0
16	9.1	43.6	40.6	33.3	30.3	17.0
20	10.2	42.0	39.0	31.4	28.4	17.0
25	11.4	40.3	37.3	29.4	26.4	16.0
31.25	12.9	38.7	35.7	27.5	24.5	15.1
62.5	18.6	33.6	30.6	21.5	18.5	12.1
100	24.0	30.1	27.1	17.4	14.4	10.0

Colors:
